Mc-ChevalierLaptop BIOS dumps, schematics & boardviews — found in seconds

Search by model or by the board number printed on the PCB. Filter by brand, device and file type, then open the original file.

Try LA-K411PThinkPad T480820-00840X541UVNM-A311

BIOS dumps
26,506
Schematics
7,738
Boardviews
6,895
Board numbers
6,212

Instant search

Results appear as you type, right in your browser. Spaces, dashes and small typos don’t matter.

Board-number aware

6,212 board numbers recognised: LA-, NM-, DA0, 6050A, 820-, BA41-, MS-, GA- and ASUS model codes.

Smart categories

124 brands, series and platforms, 8 device types and 4 file types — combine them as filters.

Straight to the source

Every file links to its original Telegram post, with the exact filename and size.

Browse by file type

Open the library

Browse by device

How it works

Three steps to the right file

Repair handbook
  1. Find the board numberLook on the PCB for LA-, NM-, DA0, 6050A, 820- or a model code like X541UV. The FRU sticker is not the board number.
  2. Search and filterType the number, then narrow by brand, device, file type and format. Words like “schematic” or “bios” work in the query too.
  3. Verify before flashingMatch the revision and flash size, and back up your own chip. Titles and “tested” claims come from uploaders.
